Pattern making

Pattern making is our playground, here we know the ropes – and have done so for over 70 years. Our decades of experience and our pattern making skills give us the capability to assist you right from the outset of the process. Starting at the consultation and construction stage and continuing through to the final product solution, we manufacture pattern from wood, plastics or metal for the hand and machine process for our customers.

Our demanding

We make pattern making Hiconform.

Our state-of-the-art manufacturing techniques combine hi-tech and craft. This is how we manufacture to the highest standards of accuracy and abrasion resistance, in reliable processes and cost-efficiently.

Our production facility

On 2000 m² of production space, we manufacture pattern models in sizes up to 4.0 m. On our CNC milling machines we process structural components with lengths up to 3.6 m and diameters up to 2.6 m. If required, we also manufacture core boxes made of plastics or wood using mechanical or pneumatic ejector systems. And naturally for us, repairs, overhauls and modifications of existing models are no problem.

Technical details:

• metal structural components sizes up to 1.700 x 800 x 800 mm
• simultaneous 5-axis machine 3.600 x 2.600 x 1.100 mm (wood and plastics)

Our construction department

At five workstations we develop, change or process the construction datasets of our customers. In this, we rely on VISI with its state-of-the-art and robust CADCAM software.

Interfaces:

• ProE, Step, SolidWorks, Parasolid, DWG, DXF
